Carton wrapping mach
Carton wrapping machine Carton wrapping machine – boxer offered by us are simple and convenient device which are used to wrap carton boxes and objects of similar geometry using stretch film delivered from powered pre-stretch unit. These are unique and highly precise and can be easily integrated into conveyor lines and are simple to operate. Following are the advantages: • protection from moisture / water • protection from dust / dirt • provides extra strength to the carton. • pilferage proof • any wiring / sticker on the outer carton surface remains completely visible till the destination • vis-a-vis any shrink machine, this system requires just 10% electricity load.. • vis-a-vis any shrink machine, this system requires just 20% space. Specifications: Product to be packed corrugated cartons / tin cans / multiple books etc • Product Dimensions 700mm x 700mm x 600mm (L x W x H) • Turntable Diameter. 1500mm (1800mm) • Max. Pallet Weight Upto 100 Kg. • Capacity Upto 150 Cartons / Hour • Direction of Rotation Clockwise (When viewed from top) • Power 1 HP 3 Phase 415 V 50 Hz AC. • Turn-Table MS Fabricated 900mm Diameter / Variable Speed • Motors AC Motors with Gear Box • Spool Carriage. 4 FRD/PE Stretch Carriage • Pre-Stretch Range Upto 300% • Stretching System Bi-Directional Wrapping • Film Usage LLDPE Stretch-Wrap Film • 250-500mm/ 12-40microns/ 76mm Following are the Advantages: • Protection from Moisture / Water • Protection from Dust / Dirt • Provides Extra Strength to the Carton. • Pilferage Proof • Any Wiring / Sticker on the outer Carton Surface remains completely visible till the destination • Vis-a-Vis any Shrink Machine, this System requires just 10% Electricity Load.. • Vis-a-Vis any Shrink Machine, this System requires just 20% Space. Specifications: Product to be Packed Corrugated Cartons / Tin Cans / Multiple Books etc Product Dimensions 700mm x 700mm x 600mm (L x W x H) Turntable Diameter. 1500mm (1800mm) Max. Pallet Weight Upto 100 Kg. Capacity Upto 150 Cartons / Hour Direction of Rotation Clockwise (When viewed from top) Power 1 HP 3 Phase 415 V 50 Hz AC Turn-Table MS Fabricated 900mm Diameter / Variable Speed Motors AC Motors with Gear Box Spool Carriage. 4 FRD/PE Stretch Carriage Pre-Stretch Range Upto 300% Stretching System Bi-Directional Wrapping Film Usage LLDPE Stretch-Wrap Film RAGHAV INTERNATIONAL LUDHIANA SOMVEER KUMAR 9646784483 9646846483 THANKS & BEST REGARDS
  • 2017-12-10T09:12:59
